Caterpillar 902 Wheel Loaders

Compare with other models

SPECS / WHEEL LOADERS

Caterpillar 902 Specs

Caterpillar 902 wheel loader specifications: type Wheel Loader, horsepower 34.3 kW, weight 4281.9 kg, tipping capacity 3039.1 kg.

All Caterpillar machines for sale

Manufacturer specifications

SpecificationMetricImperial
TypeWheel Loader
Horsepower34.3 kW46 hp
Weight4281.9 kg9440 lbs
Tipping Capacity3039.1 kg6700 lbs
Max Speed20.1 km/h12.5 mph
Engine Model3024
Displacement2200.8 cc134.3 cu in.
Net Power34.3 kW46 hp
Gross Power35.8 kW48 hp
Stroke9.9 cm3.9 in
Bore8.4 cm3.3 in
Fuel Capacity74.2 l19.6 gal
Engine Oil Capacity7.9 l2.1 gal
Cooling Capacity14.0 l3.7 gal
Hydraulic System Capacity66.2 l17.5 gal
Transmission TypeClosed-loop, two-speed Hydrostatic single-path transmission.
No of Forward Gears2
No of Reverse Gears2
Max Speed (Forward)20.1 km/h12.5 mph
Max Speed (Reverse)20.1 km/h12.5 mph
Raise Lift Arms4.5 sec
Lower Lift Time3.2 sec
Bucket Dump Time1.5 sec
Operating Weight4281.9 kg9440 lbs
Tipping Load3039.1 kg6700 lbs
Bucket Capacity (Heaped)0.5 m³0.7 cu yds
Bucket Width152.4 cm60 in
Breakout Force3773.9 kg8320 lbs
Dump Clearance At Max Raise243.8 cm96 in
Overall Length518.2 cm204 in
Ground Clearance30.5 cm12 in
Width Over Tires182.9 cm72 in

Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
