Takeuchi TW50 Specs
Takeuchi TW50 wheel loader specifications: type Wheel Loader, horsepower 38.0 kW, weight 3950.8 kg, tipping capacity 3079.9 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Wheel Loader | |
| Horsepower | 38.0 kW | 51 hp |
| Weight | 3950.8 kg | 8710 lbs |
| Tipping Capacity | 3079.9 kg | 6790 lbs |
| Max Speed | 20.0 km/h | 12.4 mph |
| Engine Model | 404 C-22 | |
| No Of Cylinders | 4 | |
| Displacement | 2220.5 cc | 135.5 cu in. |
| Alternator Supplied Amperage | 65 amps | |
| Operating Voltage | 12 V | |
| Rated Speed | 2800 RPM | |
| Torque Speed | 1800 RPM | |
| Gross Power | 38.0 kW | 51 hp |
| Peak Torque | 142.4 N-m | 105 lbs ft |
| Fuel Capacity | 61.3 l | 16.2 gal |
| Engine Oil Capacity | 10.2 l | 2.7 gal |
| Cooling Capacity | 4.5 l | 1.2 gal |
| Hydraulic System Capacity | 60.2 l | 15.9 gal |
| Transmission Type | Hydrostatic | |
| Rear Axle Oscillation | 24 ° | |
| Max Speed (Forward) | 20.0 km/h | 12.4 mph |
| Max Speed (Reverse) | 20.0 km/h | 12.4 mph |
| Pump Flow | 60.2 LPM | 15.9 GPM |
| Relief Pressure | 3336 | |
| Raise Lift Arms | 5 sec | |
| Lower Lift Time | 4 sec | |
| Bucket Dump Time | 1.5 sec | |
| Operating Weight | 3950.8 kg | 8710 lbs |
| Tipping Load | 3079.9 kg | 6790 lbs |
| Bucket Capacity (Heaped) | 0.8 m³ | 1.1 cu yds |
| Bucket Width | 182.9 cm | 72 in |
| Breakout Force | 4077.8 kg | 8990 lbs |
| Reach At Max Lift And Dump | 30.5 cm | 12 in |
| Dump Clearance At Max Raise | 243.8 cm | 96 in |
| Wheelbase | 213.4 cm | 84 in |
| Bucket Hinge Pin | 335.3 cm | 132 in |
| Cab Height | 243.8 cm | 96 in |
| Overall Length | 518.2 cm | 204 in |
| Ground Clearance | 30.5 cm | 12 in |
| Width Over Tires | 152.4 cm | 60 in |
| Tire Size | Heavy Duty - 12.5/80-18 10-ply / Flotation 15-19.5 8-ply |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
