New Holland LW230B Specs
New Holland LW230B wheel loader specifications: type Wheel Loader, horsepower 143.2 kW, weight 20729.2 kg, tipping capacity 17118.6 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Wheel Loader | |
| Horsepower | 143.2 kW | 192 hp |
| Weight | 20729.2 kg | 45700 lbs |
| Tipping Capacity | 17118.6 kg | 37740 lbs |
| Max Speed | 40.1 km/h | 24.9 mph |
| Engine Model | Cummins 6CTAA 8.3 | |
| No Of Cylinders | 6 | |
| Aspiration | Turbocharged, air to air cooled | |
| Displacement | 8300.1 cc | 506.5 cu in. |
| Alternator Supplied Amperage | 50 amps | |
| Operating Voltage | 24 V | |
| Rated Speed | 2000 RPM | |
| Torque Speed | 1400 RPM | |
| Net Power | 143.2 kW | 192 hp |
| Gross Power | 135.0 kW | 181 hp |
| Peak Torque | 1146.1 N-m | 845.3 lbs ft |
| Torque Rise | 25 % | |
| Fuel Capacity | 325.2 l | 85.9 gal |
| Engine Oil Capacity | 17.0 l | 4.5 gal |
| Cooling Capacity | 47.3 l | 12.5 gal |
| Hydraulic System Capacity | 140.1 l | 37 gal |
| Transmission Oil Capacity | 32.2 l | 8.5 gal |
| Differential Front Capacity | 34.1 l | 9 gal |
| Differential Rear Capacity | 34.1 l | 9 gal |
| Transmission Type | Power shift | |
| No of Forward Gears | 4 | |
| No of Reverse Gears | 4 | |
| Rear Axle Oscillation | 26 ° | |
| Max Speed (Forward) | 40.1 km/h | 24.9 mph |
| Max Speed (Reverse) | 43.1 km/h | 26.8 mph |
| Pump type | 2 x | Gear |
| Pump Flow | 359.2 LPM | 94.9 GPM |
| Relief Pressure | 175.0 bar | 2538.2 psi |
| Raise Lift Arms | 5.9 sec | |
| Lower Lift Time | 3.5 sec | |
| Bucket Dump Time | 1.5 sec | |
| Operating Weight | 20729.2 kg | 45700 lbs |
| Tipping Load | 17118.6 kg | 37740 lbs |
| Bucket Capacity (Heaped) | 3.7 m³ | 4.8 cu yds |
| Bucket Capacity (Struck) | 3.2 m³ | 4.2 cu yds |
| Bucket Width | 304.8 cm | 120 in |
| Breakout Force | 17898.7 kg | 39460 lbs |
| Reach At Max Lift And Dump | 121.9 cm | 48 in |
| Dump Clearance At Max Raise | 304.8 cm | 120 in |
| Wheelbase | 335.3 cm | 132 in |
| Bucket Hinge Pin | 426.7 cm | 168 in |
| Cab Height | 365.8 cm | 144 in |
| Overall Length | 823.0 cm | 324 in |
| Ground Clearance | 30.5 cm | 12 in |
| Width Over Tires | 304.8 cm | 120 in |
| Tire Size | 26.5 x25 XHA Michelin |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
