Kubota R310 Specs
Kubota R310 wheel loader specifications: type Wheel Loader, horsepower 18.0 kW, weight 1991.3 kg, engine model Kubota V1305-E-RP.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Wheel Loader | |
| Horsepower | 18.0 kW | 24.2 hp |
| Weight | 1991.3 kg | 4390 lbs |
| Engine Model | Kubota V1305-E-RP | |
| No Of Cylinders | 4 | |
| Displacement | 1335.5 cc | 81.5 cu in. |
| Rated Speed | 2600 RPM | |
| Gross Power | 18.0 kW | 24.2 hp |
| Fuel Capacity | 26.1 l | 6.9 gal |
| Hydraulic System Capacity | 20.1 l | 5.3 gal |
| Transmission Type | Load Sensing Transmission | |
| Raise Lift Arms | 3.9 sec | |
| Lower Lift Time | 1 sec | |
| Bucket Dump Time | 2.5 sec | |
| Operating Weight | 1991.3 kg | 4390 lbs |
| Breakout Force | 18.1 kg | 40 lbs |
| Reach At Max Lift And Dump | 61.0 cm | 24 in |
| Wheelbase | 152.4 cm | 60 in |
| Bucket Hinge Pin | 243.8 cm | 96 in |
| Ground Clearance | 30.5 cm | 12 in |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
