John Deere 244E Specs
John Deere 244E wheel loader specifications: type Wheel Loader, horsepower 41.0 kW, weight 5329.7 kg, tipping capacity 4050.6 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Wheel Loader | |
| Horsepower | 41.0 kW | 55 hp |
| Weight | 5329.7 kg | 11750 lbs |
| Tipping Capacity | 4050.6 kg | 8930 lbs |
| Max Speed | 32.2 km/h | 20 mph |
| Engine Model | 4 TN100 | |
| No Of Cylinders | 4 | |
| Aspiration | Naturally | |
| Displacement | 3457.7 cc | 211 cu in. |
| Alternator Supplied Amperage | 25 amps | |
| Operating Voltage | 24 V | |
| Rated Speed | 2200 RPM | |
| Torque Speed | 1300 RPM | |
| Net Power | 41.0 kW | 55 hp |
| Gross Power | 44.0 kW | 59 hp |
| Peak Torque | 246.8 N-m | 182 lbs ft |
| Torque Rise | 39 % | |
| Fuel Capacity | 70.0 l | 18.5 gal |
| Engine Oil Capacity | 12.9 l | 3.4 gal |
| Cooling Capacity | 13.2 l | 3.5 gal |
| Hydraulic System Capacity | 60.2 l | 15.9 gal |
| Transmission Oil Capacity | 10.2 l | 2.7 gal |
| Differential Front Capacity | 9.8 l | 2.6 gal |
| Differential Rear Capacity | 9.8 l | 2.6 gal |
| Transmission Type | Power shift | |
| No of Forward Gears | 2 | |
| No of Reverse Gears | 2 | |
| Rear Axle Oscillation | 22 ° | |
| Max Speed (Forward) | 32.2 km/h | 20 mph |
| Max Speed (Reverse) | 32.2 km/h | 20 mph |
| Pump type | Gear | |
| Pump Flow | 78.0 LPM | 20.6 GPM |
| Relief Pressure | 206.2 bar | 2990 psi |
| Raise Lift Arms | 4.7 sec | |
| Lower Lift Time | 3.8 sec | |
| Bucket Dump Time | 0.9 sec | |
| Operating Weight | 5329.7 kg | 11750 lbs |
| Tipping Load | 4050.6 kg | 8930 lbs |
| Bucket Capacity (Heaped) | 0.8 m³ | 1 cu yds |
| Bucket Capacity (Struck) | 0.7 m³ | 0.9 cu yds |
| Bucket Width | 213.4 cm | 84 in |
| Breakout Force | 4599.4 kg | 10140 lbs |
| Reach At Max Lift And Dump | 91.4 cm | 36 in |
| Dump Clearance At Max Raise | 243.8 cm | 96 in |
| Turning Radius | 365.8 cm | 144 in |
| Wheelbase | 213.4 cm | 84 in |
| Bucket Hinge Pin | 304.8 cm | 120 in |
| Cab Height | 304.8 cm | 120 in |
| Overall Length | 487.7 cm | 192 in |
| Ground Clearance | 30.5 cm | 12 in |
| Width Over Tires | 182.9 cm | 72 in |
| Tire Size | 17.5 /65-20 |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
