| Manufacturer | Case |
|---|---|
| Model | 430CK Construction King |
| Horsepower TOP | 42.0 HP (31.3 kW) |
| Weight TOP | Gasoline: 3439.2 lbs (1560.0 kg) Diesel: 3626.6 lbs (1645.0 kg) |
| Transmission Type TOP | Mechanical shuttle with dry disc clutch |
| Length TOP | Gasoline: 116.5 in. (296.0 cm) Diesel: 117.7 in. (299.0 cm) |
| Pump Flow TOP | Loader: 13.5 GPM (51.1 LPM) Backhoe: 16.5 GPM (62.5 LPM) |
| Years Made | 1960-1966 |
| Engine Model | J.I. Case G-188D |
| Engine Type | 4-stroke, liquid-cooled, inline |
| Fuel Type | Diesel |
| Cylinders | 4 |
| Horsepower | 42.0 HP (31.3 kW) |
| Displacement | 188.0 cu in. (3081 cc) |
| Bore | 3.82 in. (9.70 cm) |
| Stroke | 4.13 in. (10.49 cm) |
| Rear PTO Type | Transmission or live |
| Rear PTO Speed | 540 RPM |
| Torque Power | 1250 RPM |
| Torque Speed | 133.0 lb-ft (180.3 N·m) |
| Rated RPM | 1750 RPM |
| Compression Ratio | 17.5:1 |
| Spark Plug | Champion D16, Autolite BT3 |
| Starter | Electric |
| Length | Gasoline: 116.5 in. (296.0 cm) Diesel: 117.7 in. (299.0 cm) |
| Height | Steering Wheel Height: 59.1 in. (150.0 cm) |
| Wheelbase | Gasoline: 77.2 in. (196.0 cm) Diesel: 78.3 in. (199.0 cm) |
| Ground Clearance | Front axle: 15.4 in. (39.0 cm) |
| Fuel Tank Capacity | 22.0 gal (83.3 l) |
| Oil Capacity | 1.2 gal (4.7 l) |
| Coolant Capacity | 4.1 gal (15.6 l) |
| Transmission Oil Capacity | 4.3 gal (16.1 l) |
| Engine Oil Type | SAE 10W, 20W, 30 |
| Transmission Type | Mechanical shuttle with dry disc clutch |
| Gears | 4 forward and 4 reverse |
| Chassis | 4×2 2WD |
| Max. Travel Speed | Forward: 17.3 MPH (27.8 km/h) Reverse: 21.6 MPH (34.8 km/h) |
| Brakes | Mechanical disc |
| Cabin Type | Open operator station |
| Steering Type | Power |
| Front Tires | Industrial: 7.50-16, 6.50-16 |
| Rear Tires | Industrial: 14.9-24, 13.6-24, 16.9-24 |
| Hydraulic Type | Open center |
| Pump Flow | Loader: 13.5 GPM (51.1 LPM) Backhoe: 16.5 GPM (62.5 LPM) |
| Weight | Gasoline: 3439.2 lbs (1560.0 kg) Diesel: 3626.6 lbs (1645.0 kg) |
Case 430CK Construction King Specs (Weight, Lift Capacity, Hp, Dimensions)
