| Manufacturer | Case |
|---|---|
| Type | Skid steer |
| Model | 1835 Diesel |
| Lift Design | Radial |
| Years Made | 1980-1982 |
| Horsepower | 34.0 HP (25.4 kW) |
| Rating Operating Capacity (35% Tipping) | 850 lbs (385.6 kg) |
| Rating Operating Capacity (50% Tipping) | 1200 lbs (544.3 kg) |
| Operating Weight | 4550 lbs (2063.8 kg) |
| Tipping Load | 2400 lbs (1088.6 kg) |
| Lift Breakout Force | 2250 lbs (1020.6 kg) |
| Tilt Breakout Force | 3100 lbs (1406.1 kg) |
| Maximum Travel Speed | 6.1 mph (9.8 km) |
| Pump Capacity | 15.5 GPM (58.7 LPM) |
| Relief Valve Pressure | 2250 psi (155.1 Bar) |
| Optional Pump Capacity | N/A |
| Hydraulic Tank Capacity | 6.5 gal (24.6 L) |
| Raise Lift Arms | 4.8 seconds |
| Lower Lift Arms | 3.0 seconds |
| Bucket Rollback | 1.9 seconds |
| Bucket Dump | 2.3 seconds |
| Engine Manufacturer | Case |
| Engine Model | 188D |
| Engine Type | Diesel |
| No of Cylinders | 4 |
| Rated Speed | 2100 RPM |
| Gross Power | 36.0 HP (26.8 kW) |
| Displacement | 188 cu in. (3080 cc) |
| Bore | 3.8 in. (9.7 cm) |
| Stroke | 4.1 in. (10.5 cm) |
| Coolant Capacity | 4.0 gal (15.1 L) |
| Engine Oil Capacity | 1.7 gal (6.6 L) |
| Fuel Tank Capacity | 14.5 gal (55.0 L) |
| Cab Height | 80.8 in. (205.1 cm) |
| Bucket Hinge Pin Height | 110.0 in. (279.4 cm) |
| Width | 54 in. (137.9 cm) |
| Length with Bucket | 112.1 in. (284.7 cm) |
| Dump Height | 84.0 in. (213.4 cm) |
| Dump Reach | 19.0 in. (48.3 cm) |
| Ground Clearance | 6.8 in. (17.3 cm) |
| Dump Angle | 40° |
| Front Tire | 10 x 16.5 |
| Rear Tire | 10 x 16.5 |
Case 1835 Specs (Weight, Lift Capacity, Hp, Dimensions)
