Case 1120 Specs
Case 1120 compact and multi-purpose tractor specifications: tractor type Compact Utility Tractor, horsepower 14.2 kW, weight 670.0 kg, lift capacity 635.0 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Tractor Type | Compact Utility Tractor | |
| Horsepower | 14.2 kW | 19.0 HP |
| Weight | 670.0 kg | 2WD: 1377.9 lbs (625.0 kg) 4WD: 1477.1 lbs |
| Lift Capacity | 635.0 kg | 1399.9 lbs |
| Transmission Type | Hydrostatic | |
| Length | 270.0 cm | 106.3 in. |
| Pump Flow | 20.4 LPM | 5.4 GPM |
| Years Made | 1991 | |
| Engine Model | Mitsubishi | |
| Engine Type | 4-stroke, liquid-cooled, inline | |
| Fuel Type | Diesel | |
| Cylinders | 3 | |
| Displacement | 1060 cc | 64.7 cu in. |
| Bore | 7.59 cm | 2.99 in. |
| Stroke | 7.80 cm | 3.07 in. |
| Rear PTO Type | Transmission or live | |
| Rear PTO Speed | 540 RPM | |
| Middle PTO Type | Independent | |
| Middle PTO Speed | 2000 RPM | |
| Rated RPM | 2500 RPM | |
| Battery | 12 V | |
| Starter | Electric | |
| Height | 200.0 cm | Height with ROPS: 78.7 in. |
| Width | 117.0 cm | 46.1 in. |
| Wheelbase | 147.0 cm | 57.9 in. |
| Fuel Tank Capacity | 20.1 l | 5.3 gal |
| Gears | Infinite forward and reverse | |
| Chassis | 4×2 2WD or 4×4 MFWD 4WD | |
| Brakes | Mechanical drum | |
| Drawbar Category | I | |
| Cabin Type | Two-post folding ROPS | |
| Steering Type | Power | |
| Front Tires | Ag: 4.00-12 , 6-12 | |
| Rear Tires | Ag: 9.5-16 | |
| Hydraulic Type | Open center | |
| Steering Flow | 12.1 LPM | 3.2 GPM |
| Working Pressure | 147.1 bar | 2133.0 psi |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
