New Holland L125 Specs
New Holland L125 skid steer specifications: type Skid steer, lift design Vertical, years made 2005-2009, horsepower 12.3 kW.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Skid steer | |
| Lift Design | Vertical | |
| Years Made | 2005-2009 | |
| Horsepower | 12.3 kW | 16.5 HP |
| Rating Operating Capacity (35% Tipping) | 238.1 kg | 525 lbs |
| Rating Operating Capacity (50% Tipping) | 317.7 kg | 700 lbs |
| Operating Weight | 997.9 kg | 2200 lbs |
| Tipping Load | 635.0 kg | 1400 lbs |
| Lift Breakout Force | 635.0 kg | 1400 lbs |
| Tilt Breakout Force | 521.6 kg | 1150 lbs |
| Maximum Travel Speed | 9.3 km | 5.8 mph |
| Pump Capacity | 30.3 LPM | 8.0 GPM |
| Relief Valve Pressure | 110.3 Bar | 1600 psi |
| Hydraulic Tank Capacity | 34.1 L | 9.0 gal |
| Raise Lift Arms | 5.5 seconds | |
| Lower Lift Arms | 3.4 seconds | |
| Bucket Rollback | 1.9 seconds | |
| Bucket Dump | 0.9 seconds | |
| Engine Manufacturer | New Holland | |
| Engine Model | NH673 | |
| Engine Type | Diesel | |
| No of Cylinders | 3 | |
| Rated Speed | 2900 RPM | |
| Torque Speed | 1700 RPM | |
| Combustion Chamber | Direct injection | |
| Emissions | Tier 3 | |
| Firing Order | 1-2-3 | |
| Gross Power | 12.3 kW | 16.5 HP |
| Displacement | 675 cc | 41.2 cu in. |
| Bore | 6.7 cm | 2.6 in. |
| Stroke | 6.4 cm | 2.5 in. |
| Peak Torque | 38 N∙m | 28.2 ft-lb |
| Coolant Capacity | 4.4 L | 1.2 gal |
| Engine Oil Capacity | 3.0 L | 0.8gal |
| Fuel Tank Capacity | 22.7 L | 6.0 gal |
| Cab Height | 176.3 cm | 69.4 in. |
| Bucket Hinge Pin Height | 237.7 cm | 93.6 in. |
| Width | 80.8 cm | 31.8 in. |
| Length with Bucket | 241.8 cm | 95.2 in. |
| Dump Height | 157.0 cm | 61.8 in. |
| Dump Reach | 54.4 cm | 21.4 in. |
| Ground Clearance | 17.3 cm | 6.8 in. |
| Dump Angle | 34 ° | |
| Rollback Angle | 25 ° | |
| Departure Angle | 16 ° | |
| Front Tire | 8.50-12 | |
| Rear Tire | 8.50-12 |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
