JCB Fastrac 155 Specs
JCB Fastrac 155 agricultural tractor specifications: tractor type Farm Tractor, horsepower 125.3 kW, weight 6520.0 kg, lift capacity 3000.0 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Tractor Type | Farm Tractor | |
| Horsepower | 125.3 kW | 168.1 HP |
| Weight | 6520.0 kg | 14374.1 lbs |
| Lift Capacity | 3000.0 kg | 6613.9 lbs |
| Transmission Type | Synchromesh | |
| Length | 576.0 cm | 226.8 in. |
| Pump Flow | 60.0 LPM | 15.8 GPM |
| Years Made | 1993-1997 | |
| Engine Model | Perkins 1000-6 T4 | |
| Engine Type | 4-stroke, liquid-cooled, inline | |
| Fuel Type | Diesel | |
| Cylinders | 6 | |
| Displacement | 5984 cc | 365.2 cu in. |
| Bore | 10.01 cm | 3.94 in. |
| Stroke | 12.70 cm | 5.00 in. |
| Rear PTO Type | Independent with electro-hydraulic clutch | |
| Rear PTO Speed | 540 /1.000, 1.000 RPM | |
| Front PTO Type | Independent | |
| Front PTO Speed | 540 /1.000, 1.000 RPM | |
| Torque Power | 1400 RPM | |
| Torque Speed | 602.0 N·m | 444.0 lb-ft |
| Rated RPM | 2400 RPM | |
| Battery | Two 12V | |
| Starter | Electric | |
| Height | 289.0 cm | 113.8 in. |
| Wheelbase | 300.0 cm | 118.1 in. |
| Ground Clearance | 48.0 cm | 18.9 in. |
| Fuel Tank Capacity | 280.0 l | 74.0 gal |
| Hydraulic Capacity | 76.8 l | 15.9 gal (60.0 l) 20.3 gal |
| Gears | 36 forward and 12 reverse | |
| Chassis | 4×4 4WD | |
| Brakes | Pneumatic dry disc | |
| Differential Lock | Electro-hydraulic rear | |
| Drawbar Category | II | |
| Cabin Type | Cab standard with air conditioning | |
| Hitch Type | Electronic draft control | |
| Steering Type | Power assist | |
| Front Tires | Ag: 480/70R30 | |
| Rear Tires | Ag: 480/70R30 | |
| Working Pressure | 209.9 bar | 3045.0 psi |
| Valves | 2 |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
