Hitachi JD315V Specs
Hitachi JD315V backhoe loader specifications: pump capacity 136.3 LPM, lift capacity 4141.3 kg, engine manufacturer Tata, engine model 497 TC.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Pump Capacity | 136.3 LPM | 36 GPM |
| Lift Capacity | 4141.3 kg | 9130 lbs |
| Engine Manufacturer | Tata | |
| Engine Model | 497 TC | |
| Engine Type | Diesel | |
| Aspiration | Turbocharged | |
| Fuel Capacity | 136.3 l | 36 gal |
| Oil Capacity | 9.5 l | 2.5 gal |
| Cooling Capacity | 22.0 l | 5.8 gal |
| Hydraulic System Capacity | 91.2 l | 24.1 gal |
| Transmission Oil Capacity | 14.0 l | 3.7 gal |
| Front Axle Oil Capacity | 8.7 l | 2.3 gal |
| Rear Axle Oil Capacity | 14.0 l | 3.7 gal |
| No Of Forward Gears | 4 | |
| No Of Reverse Gears | 4 | |
| Max Speed (Forward) | 41.5 km/h | 25.8 mph |
| Max Speed (Reverse) | 46.3 km/h | 28.8 mph |
| Pump Type | Hydraulic with gear type tandem pump | |
| Pump Flow Capacity | 136.3 LPM | 36 GPM |
| Dig Depth | 426.7 cm | 168 in |
| Dig Depth (Extended) | 548.6 cm | 216 in |
| Loading Height | 365.8 cm | 144 in |
| Loading Height (Extended) | 426.7 cm | 168 in |
| Reach At Max Dump Height | 61.0 cm | 24 in |
| Dump Height | 335.3 cm | 132 in |
| Reach From Swivel (Extended) | 670.6 cm | 264 in |
| Lift Capacity At Full Height | 4141.3 kg | 9130 lbs |
| Bucket Capacity | 1.0 m³ | 1.31 cu yds |
| Reach From Swivel | 548.6 cm | 216 in |
| Overall Height | 518.2 cm | 204 in |
| Overall Length | 518.2 cm | 204 in |
| Overall Width | 243.8 cm | 96 in |
| Wheelbase | 213.4 cm | 84 in |
| Turning Radius | 426.7 cm | 168 in |
| Ground Clearance | 30.5 cm | 12 in |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
