| Tractor Type | Agricultural Crawler Tractor |
|---|---|
| Manufacturer | Caterpillar |
| Model | D2 |
| Weight TOP | 1939: 7418.5 lbs (3365.0 kg) 1955: 8531.9 lbs (3870.0 kg) |
| Transmission Type TOP | Gear type with dry disc clutch |
| Length TOP | 107.9 in. (274.0 cm) |
| Years Made | 1938-1957 |
| Engine Model | Caterpillar |
| Engine Type | 4-stroke, liquid-cooled, inline |
| Fuel Type | Diesel |
| Cylinders | 4 |
| Displacement | 252.0 cu in. (4129 cc) |
| Bore | 4.02 in. (10.21 cm) |
| Stroke | 5.00 in. (12.70 cm) |
| Torque Power | 1050 RPM |
| Torque Speed | 125.0 lb-ft (169.5 N·m) |
| Compression Ratio | 18.5:1 |
| Starter | Gasoline pony engine |
| Length | 107.9 in. (274.0 cm) |
| Height | 57.5 in. (146.0 cm) |
| Track Size | 12-inch tracks |
| Fuel Tank Capacity | liters |
| Transmission Type | Gear type with dry disc clutch |
| Gears | 5 forward and 1 reverse |
| Chassis | Crawler |
| Max. Travel Speed | Forward: 5.1 MPH (8.2 km/h) Reverse: 2.1 MPH (3.4 km/h) |
| Cabin Type | Open operator station |
| Steering Type | Mechanical clutches |
| Weight | 1939: 7418.5 lbs (3365.0 kg) 1955: 8531.9 lbs (3870.0 kg) |
