Case 9007B Specs
Case 9007B mid-size excavator specifications: excavator type Mid-Size Excavator, weight 6900 kg, horsepower 40 kW, digging depth 418 cm.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Excavator Type | Mid-Size Excavator | |
| Weight | 6900 kg | 15212 lbs |
| Horsepower | 40 kW | 54 HP |
| Digging Depth | 418 cm | 164 in. |
| Max Digging Depth | 418 cm | 164 in. |
| Max Loading Height | 515.1 cm | 202.8 in. |
| Max Reach Along Ground | 624.8 cm | 246.0 in. |
| Max Vertical Wall Digging Depth | 350.5 cm | 138.0 in. |
| Overall Length | 603.5 cm | 237.6 in. |
| Reference Bucket Capacity | 0.4 m2 | 0.5 cu yds |
| Max Bucket Capacity | 0.5 m2 | 0.7 cu yds |
| Min Bucket Capacity | 0.2 m2 | 0.3 cu yds |
| Ground Clearance | 36.6 cm | 14.4 in. |
| Tail Swing Radius | 176.8 cm | 69.6 in. |
| Overall Width | 216.4 cm | 85.2 in. |
| Engine Make | Isuzu | |
| Engine Model | 4 JB1 | |
| Net Power | 40 kW | 54 HP |
| Gross Power | 44.2 kW | 59.3 HP |
| Rated Power | 2100 RPM | |
| Hydraulic Pump Flow Capacity | 151 LPM | 40 GPM |
| Hydraulic System Capacity | 95.0 l | 25.1 gal |
| Relief Valve Pressure | 303 Bar | 4400 psi |
| Operating Weight | 6900 kg | 15212 lbs |
| Max Travel Speed | 5.0 km | 3.1 mph |
| Swing Speed | 13.5 RPM | |
| Cab Height | 265.2 cm | 104.4 in. |
| Max Torque | 188.5 Nm | 139.0 ft-lbs |
| Cooling Capacity | 10.2 l | 2.7 gal |
| Fuel Capacity | 140.1 l | 37.0 gal |
| Engine Oil Capacity | 10.2 l | 2.7 gal |
| Operating Voltage | Operating Voltage 24 V | |
| Ground Pressure | 33.8 kPa | 4.9 psi |
| Number of Carrier Rollers per Side | 1 | |
| Number of Track Rollers per Side | 5 | |
| Number of Shoes per Side | 42 | |
| Displacement | 2769.4 cc | 169 cu. in. |
| Shoe Size | 45.0 cm | 17.7 in. |
| No of Cylinders | 4 | |
| Max Cutting Height | 725.4 cm | 285.6 in. |
| Alternator | 40 A | |
| Removal Counterweight Clearance | 76.2 cm | 30.0 in. |
| Torque Power | 1600 RPM | |
| Drawbar Pull | 5.000 kg | 11023 lbs |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
