SPECS / COMPARISON
Bobcat S650 vs Kubota Ssv75
A detailed comparison of the Bobcat S650 and the Kubota Ssv75. Click a model name to view its full specifications.
Horsepower
Bobcat S65055.4 kW (74.3 HP)
Kubota Ssv7555.4 kW (74.3 HP)
Operating Weight
Bobcat S6503777.1 kg (8327 lbs)
Kubota Ssv753819.8 kg (8421 lbs)
| Specification | Bobcat S650 Skid Steers | Kubota Ssv75 Skid Steers |
|---|---|---|
| Type | Skid steer | Skid steer |
| Lift Design | Vertical | Vertical |
| Years Made | 2014-2022 | 2015-2022 |
| Horsepower | 55.4 kW (74.3 HP) | 55.4 kW (74.3 HP) |
| Rating Operating Capacity (50% Tipping) | 1220.2 kg (2690 lbs) | 1220.2 kg (2690 lbs) |
| Operating Weight | 3777.1 kg (8327 lbs) | 3819.8 kg (8421 lbs) |
| Tipping Load | 2440.3 kg (5380 lbs) | 2440.0 kg (5379 lbs) |
| Lift Breakout Force | 2177.2 kg (4800 lbs) | 2199.9 kg (4850 lbs) |
| Tilt Breakout Force | 2313.3 kg (5100 lbs) | 2667.1 kg (5880 lbs) |
| Maximum Travel Speed | 19.8 km (12.3 mph) | 19.0 km (11.8 mph) |
| Pump Capacity | 87.1 LPM (23.0 GPM) | 79.0 LPM (20.9 GPM) |
| Relief Valve Pressure | 241.3 Bar (3500 psi) | 225.5 Bar (3271 psi) |
| Optional Pump Capacity | 115.5 LPM (30.5 GPM) | 115.0 LPM (30.4 GPM) |
| Hydraulic Tank Capacity | 45.0 L (11.9 gal) | 16.0 L (4.2 gal) |
| Raise Lift Arms | 3.4 seconds | — |
| Lower Lift Arms | 3.0 seconds | — |
| Bucket Rollback | 2.3 seconds | — |
| Bucket Dump | 1.7 seconds | — |
| Engine Manufacturer | Kubota | Kubota |
| Engine Model | V3307-DI-TE3 | V3307-CR-TE5B |
| Engine Type | Diesel | Diesel |
| No of Cylinders | 4 | 4 |
| Rated Speed | 2400 RPM | 2600 RPM |
| Torque Speed | 1600 RPM | 1500 RPM |
| Combustion Chamber | Direct injection | Direct injection |
| Emissions | Tier 4 | Tier 4 |
| Compression Ratio | 22.6 | 15:6 |
| Firing Order | 1-3-4-2 | 1-3-4-2 |
| Gross Power | 55.4 kW (74.3 HP) | 55.4 kW (74.3 HP) |
| Displacement | 3318 cc (202.5 cu in.) | 3331 cc (203.3 cu in.) |
| Bore | 9.4 cm (3.7 in.) | 9.4 cm (3.7 in.) |
| Stroke | 12.0 cm (4.7 in.) | 12.0 cm (4.7 in.) |
| Peak Torque | 264.4 N∙m (195.0 ft-lb) | 260.3 N∙m (192 ft-lb) |
| Coolant Capacity | 11.7 L (3.1 gal) | 14.0 L (3.7 gal) |
| Engine Oil Capacity | 11.4 L (3.0 gal) | 11.8 L (3.1 gal) |
| Fuel Tank Capacity | 103.1 L (27.2 gal) | 102.0 L (26.9 gal) |
| Cab Height | 206.5 cm (81.3 in.) | 206.5 cm (81.3 in.) |
| Bucket Hinge Pin Height | 314.9 cm (124.0 in.) | 325.8 cm (128.3 in.) |
| Width | 183.2 cm (72.1 in.) | 182.3 cm (71.8 in.) |
| Length with Bucket | 347.4 cm (136.8 in.) | 366.0 cm (144.1 in.) |
| Dump Height | 244.7 cm (96.3 in.) | 249.0 cm (98.0 in.) |
| Dump Reach | 80.0 cm (31.5 in.) | 93.6 cm (36.9 in.) |
| Ground Clearance | 20.7 cm (8.1 in.) | 20.7 cm (8.1 in.) |
| Dump Angle | 42 ° | 43 ° |
| Rollback Angle | 31 ° | 27 ° |
| Departure Angle | 25 ° | 25 ° |
| Front Tire | 12-16.5 | 12-16.5-10PR |
| Rear Tire | 12-16.5 | 12-16.5-10PR |
| Rating Operating Capacity (35% Tipping) | — | 852.8 kg (1880 lbs) |
Values come from the manufacturer-sourced model files; empty cells mean the property is not published for that model. No performance ranking is applied.
