| Manufacturer | Bobcat |
|---|---|
| Type | Skid steer |
| Model | 751C |
| Lift Design | Vertical |
| Years Made | 1992-2000 |
| Horsepower | 37.5 HP (12.3 kW) |
| Rating Operating Capacity (35% Tipping) | 750 lbs (340.2 kg) |
| Rating Operating Capacity (50% Tipping) | 1300 lbs (589.7 kg) |
| Operating Weight | 5000 lbs (2267.9 kg) |
| Tipping Load | 2500 lbs (1134.0 kg) |
| Lift Breakout Force | 2360 lbs (1070.5 kg) |
| Tilt Breakout Force | 2380 lbs (1079.5 kg) |
| Maximum Travel Speed | 6.1 mph (9.8 km) |
| Pump Capacity | 12.9 GPM (49.0 LPM) |
| Relief Valve Pressure | 2550 psi (175.8 Bar) |
| Optional Pump Capacity | N/A |
| Hydraulic Tank Capacity | 5.8 gal (22 L) |
| Raise Lift Arms | 3.4 seconds |
| Lower Lift Arms | 2.1 seconds |
| Bucket Rollback | 2.0 seconds |
| Bucket Dump | 2.4 seconds |
| Engine Manufacturer | Kubota |
| Engine Model | V1903E |
| Engine Type | Diesel |
| No of Cylinders | 4 |
| Rated Speed | 2700 RPM |
| Torque Speed | 1800 RPM |
| Combustion Chamber | Spherical Type (E TVCS) |
| Compression Ratio | 23:1 |
| Firing Order | 1-3-4-2 |
| Gross Power | 37.5 HP (28.0 kW) |
| Displacement | 113 cu. in. (1857 cc) |
| Bore | 3.2 in. (8.0 cm) |
| Stroke | 3.6 in. (9.2 cm) |
| Peak Torque | 86.3 ft-lb (117.0 N∙m) |
| Coolant Capacity | 3.2 gal (12.3 L) |
| Engine Oil Capacity | 1.9 gal (7.1 L) |
| Fuel Tank Capacity | 14.0 gal (53.0 L) |
| Cab Height | 76.0 in. (193.0 cm) |
| Bucket Hinge Pin Height | 109.1 in. (277.1 cm) |
| Width | 54.0 in. (137.2 cm) |
| Length with Bucket | 122.2 in. (310.5 cm) |
| Dump Height | 84.6 in. (214.8 cm) |
| Dump Reach | 19.1 in. (48.5 cm) |
| Ground Clearance | 7.1 in. (18.0 cm) |
| Dump Angle | 40° |
| Rollback Angle | 25° |
| Departure Angle | 26° |
| Front Tire | 10-16.5 |
| Rear Tire | 10-16.5 |
Bobcat 751 Specs (Weight, Lift Capacity, Hp, Dimensions)
