Volvo L330C Specs
Volvo L330C crawler dozer specifications: type Wheel Loader, horsepower 371.4 kW, weight 48430.0 kg, tipping capacity 35230.5 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Wheel Loader | |
| Horsepower | 371.4 kW | 498 hp |
| Weight | 48430.0 kg | 106770 lbs |
| Tipping Capacity | 35230.5 kg | 77670 lbs |
| Max Speed | 34.3 km/h | 21.3 mph |
| Engine Model | TD 164 KAE | |
| No Of Cylinders | 6 | |
| Aspiration | Turbocharged and Intercooled | |
| Displacement | 16124.9 cc | 984 cu in. |
| Alternator Supplied Amperage | 80 amps | |
| Operating Voltage | 24 V | |
| Rated Speed | 1800 RPM | |
| Torque Speed | 1000 RPM | |
| Net Power | 371.4 kW | 498 hp |
| Gross Power | 375.1 kW | 503 hp |
| Peak Torque | 2370.0 N-m | 1748 lbs ft |
| Fuel Capacity | 693.1 l | 183.1 gal |
| Engine Oil Capacity | 61.3 l | 16.2 gal |
| Cooling Capacity | 90.1 l | 23.8 gal |
| Hydraulic System Capacity | 552.3 l | 145.9 gal |
| Transmission Oil Capacity | 92.4 l | 24.4 gal |
| Differential Front Capacity | 68.1 l | 18 gal |
| Differential Rear Capacity | 68.1 l | 18 gal |
| Transmission Type | Power shift | |
| No of Forward Gears | 4 | |
| No of Reverse Gears | 3 | |
| Rear Axle Oscillation | 24 ° | |
| Max Speed (Forward) | 34.3 km/h | 21.3 mph |
| Max Speed (Reverse) | 20.0 km/h | 12.4 mph |
| Pump type | Axial Piston Pump | |
| Pump Flow | 741.9 LPM | 196 GPM |
| Relief Pressure | 215.0 bar | 3118 psi |
| Raise Lift Arms | 8.5 sec | |
| Lower Lift Time | 4.5 sec | |
| Bucket Dump Time | 1.8 sec | |
| Operating Weight | 48430.0 kg | 106770 lbs |
| Tipping Load | 35230.5 kg | 77670 lbs |
| Bucket Capacity (Heaped) | 6.9 m³ | 9 cu yds |
| Bucket Capacity (Struck) | 5.9 m³ | 7.7 cu yds |
| Bucket Width | 396.2 cm | 156 in |
| Breakout Force | 47681.6 kg | 105120 lbs |
| Reach At Max Lift And Dump | 182.9 cm | 72 in |
| Dump Clearance At Max Raise | 365.8 cm | 144 in |
| Turning Radius | 914.4 cm | 360 in |
| Wheelbase | 396.2 cm | 156 in |
| Bucket Hinge Pin | 518.2 cm | 204 in |
| Cab Height | 426.7 cm | 168 in |
| Overall Length | 1005.8 cm | 396 in |
| Ground Clearance | 61.0 cm | 24 in |
| Width Over Tires | 365.8 cm | 144 in |
| Tire Size | 35 /65R33 XLD D1*L-4 |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
