SPECS / OTHER
Volvo L32 Specs
Volvo L32 specifications: type Wheel Loader, horsepower 49.2 kW, weight 5121.1 kg, tipping capacity 3851.0 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Wheel Loader | |
| Horsepower | 49.2 kW | 66 hp |
| Weight | 5121.1 kg | 11290 lbs |
| Tipping Capacity | 3851.0 kg | 8490 lbs |
| Max Speed | 20.1 km/h | 12.5 mph |
| Engine Model | BF4L 1011F | |
| No Of Cylinders | 4 | |
| Aspiration | Turbocharged | |
| Displacement | 2730.1 cc | 166.6 cu in. |
| Alternator Supplied Amperage | 80 amps | |
| Operating Voltage | 12 V | |
| Rated Speed | 2300 RPM | |
| Torque Speed | 1800 RPM | |
| Net Power | 49.2 kW | 66 hp |
| Gross Power | 51.5 kW | 69 hp |
| Peak Torque | 220.0 N-m | 162.3 lbs ft |
| Fuel Capacity | 86.3 l | 22.8 gal |
| Engine Oil Capacity | 10.6 l | 2.8 gal |
| Hydraulic System Capacity | 60.2 l | 15.9 gal |
| Differential Front Capacity | 11.4 l | 3 gal |
| Differential Rear Capacity | 12.1 l | 3.2 gal |
| Transmission Type | Hydrostatic | |
| No of Forward Gears | 2 | |
| No of Reverse Gears | 2 | |
| Rear Axle Oscillation | 20 ° | |
| Max Speed (Forward) | 20.1 km/h | 12.5 mph |
| Max Speed (Reverse) | 20.1 km/h | 12.5 mph |
| Pump type | gear type | |
| Pump Flow | 52.2 LPM | 13.8 GPM |
| Relief Pressure | 230.0 bar | 3335.9 psi |
| Raise Lift Arms | 6 sec | |
| Lower Lift Time | 3 sec | |
| Bucket Dump Time | 1.6 sec | |
| Operating Weight | 5121.1 kg | 11290 lbs |
| Tipping Load | 3851.0 kg | 8490 lbs |
| Bucket Capacity (Heaped) | 1.1 m³ | 1.4 cu yds |
| Bucket Width | 182.9 cm | 72 in |
| Breakout Force | _ - | |
| Reach At Max Lift And Dump | 91.4 cm | 36 in |
| Dump Clearance At Max Raise | 243.8 cm | 96 in |
| Turning Radius | 426.7 cm | 168 in |
| Wheelbase | 213.4 cm | 84 in |
| Bucket Hinge Pin | 335.3 cm | 132 in |
| Cab Height | 274.3 cm | 108 in |
| Overall Length | 548.6 cm | 216 in |
| Ground Clearance | 61.0 cm | 24 in |
| Width Over Tires | 182.9 cm | 72 in |
| Tire Size | 365 /80 R20 |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
