SPECS / COMPARISON
Takeuchi Ts70v vs Caterpillar 262d
A detailed comparison of the Takeuchi Ts70v and the Caterpillar 262d. Click a model name to view its full specifications.
Horsepower
Takeuchi Ts70v55.2 kW (74.0 HP)
Caterpillar 262d55.4 kW (74.3 HP)
Operating Weight
Takeuchi Ts70v3674 kg (8100 lbs)
Caterpillar 262d3633.7 kg (8011 lbs)
| Specification | Takeuchi Ts70v Skid Steers | Caterpillar 262d Skid Steers |
|---|---|---|
| Type | Skid steer | Skid steer |
| Lift Design | Vertical | Vertical |
| Years Made | 2011-2015 | 2016-2022 |
| Horsepower | 55.2 kW (74.0 HP) | 55.4 kW (74.3 HP) |
| Rating Operating Capacity (35% Tipping) | 839 kg (1850 lbs) | — |
| Rating Operating Capacity (50% Tipping) | 1203 kg (2635 lbs) | 1224.7 kg (2700 lbs) |
| Operating Weight | 3674 kg (8100 lbs) | 3633.7 kg (8011 lbs) |
| Tipping Load | 2594 kg (5270 lbs) | 2449.4 kg (5400 lbs) |
| Lift Breakout Force | 2663 kg (5871 lbs) | — |
| Tilt Breakout Force | 2666 kg (5878 lbs) | 3327.1 kg (7335 lbs) |
| Maximum Travel Speed | 13.6 km (8.5 mph) | 15.5 km (7.7 mph) |
| Optional High Speed | 19.3 km (12.0 mph) | 17.7 km (11 mph) |
| Pump Capacity | 38.0 LPM (10.0 GPM) | 87.1 LPM (23.0 GPM) |
| Relief Valve Pressure | 229.9 Bar (3335 psi) | 230.0 Bar (3335 psi) |
| Optional Pump Capacity | 106.0 LPM (28.0 GPM) | — |
| Engine Manufacturer | Perkins | Cat |
| Engine Model | 804 D-33T | C3.3B DIT |
| Engine Type | Diesel | Diesel |
| No of Cylinders | 4 | 4 |
| Rated Speed | 2500 RPM | 2400 RPM |
| Torque Speed | 1400 RPM | 1500 RPM |
| Combustion Chamber | Direct injection | Direct injection |
| Emissions | Tier 3 | Tier 4 |
| Compression Ratio | 19.0:1 | 17:1 |
| Firing Order | 1-3-4-2 | 1-3-4-2 |
| Gross Power | 55.2 kW (74.0 HP) | 55.4 kW (74.3 HP) |
| Displacement | 3294 cc (201 cu in.) | 3327 cc (203 cu in.) |
| Bore | 9.4 cm (3.7 in.) | 9.4 cm (3.7 in.) |
| Stroke | 12.0 cm (4.7 in.) | 12.0 cm (4.7 in.) |
| Peak Torque | 244 N∙m (180 ft-lb) | 359.3 N∙m (265 ft-lb) |
| Coolant Capacity | 11.0 L (2.9 gal) | 14.0 L (3.7 gal) |
| Engine Oil Capacity | 8.5 L (2.2 gal) | 11.4 L (3.0 gal) |
| Fuel Tank Capacity | 113.0 L (29.9 gal) | 93.9 L (24.8 gal) |
| Cab Height | 199.3 cm (78.5 in.) | 211.1 cm (83.1 in.) |
| Bucket Hinge Pin Height | 327.7 cm (129.0 in.) | 317.2 cm (124.9 in.) |
| Width | 167.6 cm (66.0 in.) | 167.6 cm (66.0 in.) |
| Length with Bucket | 365.3 cm (143.8 in.) | 371.3 cm (146.2 in.) |
| Dump Height | 264.4 cm (104.1 in.) | 238.0 cm (93.7 in.) |
| Dump Reach | 91.4 cm (36.0 in.) | 39.3 cm (15.5 in.) |
| Ground Clearance | 26.7 cm (10.5 in.) | 22.6 cm (8.9 in.) |
| Dump Angle | 34 ° | 51 ° |
| Rollback Angle | 30 ° | — |
| Departure Angle | 26 ° | 26 ° |
| Front Tire | 12×16.5 | 12 x 16.5 |
| Rear Tire | 12×16.5 | 12 x 16.5 |
| Hydraulic Tank Capacity | — | 196.8 L (52.0 gal) |
Values come from the manufacturer-sourced model files; empty cells mean the property is not published for that model. No performance ranking is applied.
