New Holland C232 Specs
New Holland C232 compact track loader specifications: type Compact track loader, lift design Vertical, years made 2011-2020, horsepower 55.2 kW.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Compact track loader | |
| Lift Design | Vertical | |
| Years Made | 2011-2020 | |
| Horsepower | 55.2 kW | 74.0 HP |
| Rating Operating Capacity (35% Tipping) | 1016.0 kg | 2240 lbs |
| Rating Operating Capacity (50% Tipping) | 1451.5 kg | 3200 lbs |
| Operating Weight | 4368.1 kg | 9630 lbs |
| Tipping Load | 2903.0 kg | 6400 lbs |
| Lift Breakout Force | 2195.4 kg | 4840 lbs |
| Tilt Breakout Force | 3338.4 kg | 7360 lbs |
| Maximum Travel Speed | 8.2 km | 5.1 mph |
| Optional High Speed | 12.2 km | 7.6 mph |
| Ground Pressure | 29.0 kPa | 4.2 psi |
| Pump Capacity | 91.5 LPM | 24.2 GPM |
| Relief Valve Pressure | 210.3 Bar | 3050 psi |
| Optional Pump Capacity | 142.5 LPM | 37.6 GPM |
| Hydraulic Tank Capacity | 29.2 L | 7.7 gal |
| Raise Lift Arms | 3.9 seconds | |
| Lower Lift Arms | 2.5 seconds | |
| Bucket Rollback | 2.0 seconds | |
| Bucket Dump | 2.7 seconds | |
| Engine Manufacturer | FPT | |
| Engine Model | F5H FL463A*F001 | |
| Engine Type | Diesel | |
| No of Cylinders | 4 | |
| Rated Speed | 2500 RPM | |
| Torque Speed | 1400 RPM | |
| Combustion Chamber | Direct injection | |
| Emissions | Tier 4 | |
| Firing Order | 1-3-4-2 | |
| Gross Power | 55.2 kW | 74.0 HP |
| Displacement | 3392 cc | 207 cu in. |
| Bore | 9.9 cm | 3.9 in. |
| Stroke | 11.0 cm | 4.3 in. |
| Peak Torque | 314.5 N∙m | 232 ft-lb |
| Coolant Capacity | 18.9 L | 5.0 gal |
| Engine Oil Capacity | 8.5 L | 2.2 gal |
| Fuel Tank Capacity | 96.5 L | 25.5 gal |
| Cab Height | 204.2 cm | 80.4 in. |
| Bucket Hinge Pin Height | 333.0 cm | 131.1 in. |
| Width | 193.0 cm | 76.0 in. |
| Length with Bucket | 363.0 cm | 142.9 in. |
| Dump Height | 265.5 cm | 104.5 in. |
| Dump Reach | 87.5 cm | 34.4 in. |
| Ground Clearance | 24.3 cm | 9.5 in. |
| Dump Angle | 55 ° | |
| Rollback Angle | 33 ° | |
| Departure Angle | 32 ° | |
| Track Width | 45.0 cm | 17.7 in. |
| Track Length | 302.0 cm | 118.9 in. |
| Ground Contact Length | 163.8 cm | 64.5 in. |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
