SPECS / COMPARISON
Link-Belt L120 vs Volvo 4300B
A detailed comparison of the Link-Belt L120 and the Volvo 4300B. Click a model name to view its full specifications.
Horsepower
Link-Belt L12079.0 kW (106 hp)
Volvo 4300B82.0 kW (110 hp)
Weight
Link-Belt L1209303.2 kg (20510 lbs)
Volvo 4300B9498.2 kg (20940 lbs)
Operating Weight
Link-Belt L1209303.2 kg (20510 lbs)
Volvo 4300B9498.2 kg (20940 lbs)
| Specification | Link-Belt L120 Wheel Loaders | Volvo 4300B Wheel Loaders |
|---|---|---|
| Type | Wheel Loader | Wheel Loader |
| Horsepower | 79.0 kW (106 hp) | 82.0 kW (110 hp) |
| Weight | 9303.2 kg (20510 lbs) | 9498.2 kg (20940 lbs) |
| Tipping Capacity | 6604.3 kg (14560 lbs) | 6540.8 kg (14420 lbs) |
| Max Speed | 35.6 km/h (22.1 mph) | 37.0 km/h (23 mph) |
| Engine Model | 4 BTA3.9 | BM TD 45 B |
| No Of Cylinders | 4 | 4 |
| Aspiration | Turbocharged and Intercooled | Turbocharged |
| Displacement | 3916.5 cc (239 cu in.) | 4480.2 cc (273.4 cu in.) |
| Alternator Supplied Amperage | 70 amps | 55 amps |
| Operating Voltage | 24 V | 24 V |
| Rated Speed | 2200 RPM | 2200 RPM |
| Torque Speed | 1500 RPM | 1400 RPM |
| Net Power | 79.0 kW (106 hp) | 82.0 kW (110 hp) |
| Gross Power | 82.0 kW (110 hp) | 88.0 kW (118 hp) |
| Peak Torque | 413.5 N-m (305 lbs ft) | 425.0 N-m (313.5 lbs ft) |
| Fuel Capacity | 130.2 l (34.4 gal) | 190.0 l (50.2 gal) |
| Engine Oil Capacity | 10.2 l (2.7 gal) | 11.4 l (3 gal) |
| Hydraulic System Capacity | 120.4 l (31.8 gal) | 130.2 l (34.4 gal) |
| Transmission Oil Capacity | 17.0 l (4.5 gal) | 27.3 l (7.2 gal) |
| Differential Front Capacity | 10.2 l (2.7 gal) | 26.1 l (6.9 gal) |
| Differential Rear Capacity | 10.2 l (2.7 gal) | 26.1 l (6.9 gal) |
| Transmission Type | Power shift | Power shift |
| No of Forward Gears | 4 | 4 |
| No of Reverse Gears | 3 | 4 |
| Rear Axle Oscillation | 24 ° | 26 ° |
| Max Speed (Forward) | 35.6 km/h (22.1 mph) | 37.0 km/h (23 mph) |
| Max Speed (Reverse) | 24.9 km/h (15.5 mph) | 37.0 km/h (23 mph) |
| Pump type | Variable Displacement | Vane pump |
| Pump Flow | 121.1 LPM (32 GPM) | 190.0 LPM (50.2 GPM) |
| Relief Pressure | 279.9 bar (4060 psi) | 160.0 bar (2320 psi) |
| Raise Lift Arms | 5.4 sec | 4.8 sec |
| Lower Lift Time | 3.8 sec | 2.9 sec |
| Bucket Dump Time | 1.4 sec | 3.3 sec |
| Operating Weight | 9303.2 kg (20510 lbs) | 9498.2 kg (20940 lbs) |
| Tipping Load | 6604.3 kg (14560 lbs) | 6540.8 kg (14420 lbs) |
| Bucket Capacity (Heaped) | 1.5 m³ (2 cu yds) | 1.5 m³ (2 cu yds) |
| Breakout Force | 8668.1 kg (19110 lbs) | 8396.0 kg (18510 lbs) |
| Reach At Max Lift And Dump | 91.4 cm (36 in) | 91.4 cm (36 in) |
| Dump Clearance At Max Raise | 274.3 cm (108 in) | 274.3 cm (108 in) |
| Turning Radius | 518.2 cm (204 in) | 487.7 cm (192 in) |
| Wheelbase | 274.3 cm (108 in) | 274.3 cm (108 in) |
| Bucket Hinge Pin | 365.8 cm (144 in) | 365.8 cm (144 in) |
| Cab Height | 304.8 cm (120 in) | 304.8 cm (120 in) |
| Overall Length | 670.6 cm (264 in) | 640.1 cm (252 in) |
| Ground Clearance | 30.5 cm (12 in) | 30.5 cm (12 in) |
| Width Over Tires | 213.4 cm (84 in) | 243.8 cm (96 in) |
| Tire Size | 17.5 R25 | 17.5 R25/12 |
| Cooling Capacity | — | 23.1 l (6.1 gal) |
| Bucket Width | — | 243.8 cm (96 in) |
Values come from the manufacturer-sourced model files; empty cells mean the property is not published for that model. No performance ranking is applied.
