Kubota U15 Specs
Kubota U15 mini excavator specifications: excavator type Mini Excavator, weight 1680 kg, horsepower 9 kW, digging depth 232 cm.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Excavator Type | Mini Excavator | |
| Weight | 1680 kg | 3704 lbs |
| Horsepower | 9 kW | 12 HP |
| Digging Depth | 232 cm | 91 in. |
| Max Digging Depth | 232 cm | 91 in. |
| Max Loading Height | 246.9 cm | 97.2 in. |
| Max Reach Along Ground | 384.0 cm | 151.2 in. |
| Max Vertical Wall Digging Depth | 192.0 cm | 75.6 in. |
| Overall Length | 359.7 cm | 141.6 in. |
| Ground Clearance | 15.2 cm | 6.0 in. |
| Overall Width | 125.0 cm | 49.2 in. |
| Engine Make | Kubota | |
| Engine Model | D1105 | |
| Net Power | 9 kW | 12 HP |
| Gross Power | 9 kw | 12.9 hp |
| Rated Power | 2300 RPM | |
| Hydraulic Pump Flow Capacity | 15 LPM | 4.4 GPM |
| Hydraulic System Capacity | 13.2 l | 3.5 gal |
| Operating Weight | 1680 kg | 3704 lbs |
| Max Travel Speed | 4.2 km | 2.6 mph |
| Swing Speed | 8.7 RPM | |
| Cooling Capacity | 2.6 l | 0.7 gal |
| Fuel Capacity | 17.8 l | 4.7 gal |
| Engine Oil Capacity | 3.8 l | 1.0 gal |
| Ground Pressure | 25.5 kPa | 3.7 psi |
| Displacement | 778.4 cc | 48 cu. in. |
| Max Cutting Height | 356.6 cm | 140.4 in. |
| Drawbar Pull | 1.998 kg | 4405 lbs |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
