Kubota Svl97-2 Specs
Kubota Svl97-2 compact track loader specifications: type Compact track loader, lift design Vertical, years made 2021-2022, horsepower 71.9 kW.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Compact track loader | |
| Lift Design | Vertical | |
| Years Made | 2021-2022 | |
| Horsepower | 71.9 kW | 96.4 HP |
| Rating Operating Capacity (35% Tipping) | 1451.5 kg | 3200 lbs |
| Rating Operating Capacity (50% Tipping) | 2072.9 kg | 4570 lbs |
| Operating Weight | 5248.1 kg | 11570 lbs |
| Tipping Load | 4150.4 kg | 9150 lbs |
| Lift Breakout Force | 3057.2 kg | 6740 lbs |
| Tilt Breakout Force | 3610.6 kg | 7960 lbs |
| Maximum Travel Speed | 11.7 km | 7.3 mph |
| Ground Pressure | 31.0 kPa | 4.5 psi |
| Pump Capacity | 87.4 LPM | 23.1 GPM |
| Relief Valve Pressure | 249.8 Bar | 3623 psi |
| Optional Pump Capacity | 151.4 LPM | 40.0 GPM |
| Hydraulic Tank Capacity | 68.0 L | 18.0 gal |
| Engine Manufacturer | Kubota | |
| Engine Model | V3800-TIEF4 | |
| Engine Type | Diesel | |
| No of Cylinders | 4 | |
| Rated Speed | 2400 RPM | |
| Combustion Chamber | Direct injection | |
| Emissions | Tier 4 | |
| Compression Ratio | 19.0 | |
| Firing Order | 1-3-4-2 | |
| Gross Power | 71.9 kW | 96.4 HP |
| Displacement | 3769 cc | 230 cu in. |
| Bore | 10.0 cm | 3.9 in. |
| Stroke | 12.0 cm | 4.7 in. |
| Fuel Tank Capacity | 109.0 L | 28.8 gal |
| Cab Height | 211.6 cm | 83.3 in. |
| Bucket Hinge Pin Height | 326.4 cm | 128.5 in. |
| Width | 196.2 cm | 77.2 in. |
| Length with Bucket | 392.9 cm | 154.7 in. |
| Dump Reach | 103.5 cm | 40.7 in. |
| Ground Clearance | 29.3 cm | 11.5 in. |
| Dump Angle | 43 ° | |
| Rollback Angle | 27 ° | |
| Departure Angle | 31 ° | |
| Track Width | 45.0 cm | 17.7 in. |
| Track Length | 313.7 cm | 123.5 in. |
| Ground Contact Length | 166.7 cm | 65.6 in. |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
