John Deere 319D Specs
John Deere 319D compact track loader specifications: type Compact track loader, lift design Vertical, years made 2005-2014, horsepower 63.4 kW.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Type | Compact track loader | |
| Lift Design | Vertical | |
| Years Made | 2005-2014 | |
| Horsepower | 63.4 kW | 85.0 HP |
| Rating Operating Capacity (35% Tipping) | 863 kg | 1900 lbs |
| Rating Operating Capacity (50% Tipping) | 1271 kg | 2800 lbs |
| Operating Weight | 3882 kg | 8550 lbs |
| Tipping Load | 2542 kg | 5600 lbs |
| Lift Breakout Force | 1589 kg | 5125 lbs |
| Tilt Breakout Force | 2327 kg | 3500 lbs |
| Maximum Travel Speed | 8.5 km | 5.3 mph |
| Optional High Speed | 12.6 km | 7.8 mph |
| Ground Pressure | 34.2 kPa | 5.0 psi |
| Pump Capacity | 94.6 LPM | 21.0 GPM |
| Relief Valve Pressure | 237.9 Bar | 3450 psi |
| Optional Pump Capacity | 128.7 LPM | 33.0 GPM |
| Engine Manufacturer | John Deere | |
| Engine Model | 5030 HT | |
| Engine Type | Diesel | |
| No of Cylinders | 4 | |
| Rated Speed | 2200 RPM | |
| Torque Speed | 2000 RPM | |
| Combustion Chamber | Direct injection | |
| Emissions | Tier 3 | |
| Compression Ratio | 18.2:1 | |
| Firing Order | 1-3-4-2 | |
| Gross Power | 63.4 kW | 85.0 HP |
| Displacement | 30448 cc | 186 cu in. |
| Bore | 8.6 cm | 3.4 in. |
| Stroke | 10.5 cm | 4.1 in. |
| Peak Torque | 300 N∙m | 221 ft-lb |
| Engine Oil Capacity | 10.0 L | 2.7 gal |
| Fuel Tank Capacity | 111 L | 29.0 gal |
| Cab Height | 215.9 cm | 85.0 in. |
| Bucket Hinge Pin Height | 320.0 cm | 126.0 in. |
| Width | 200.7 cm | 79.0 in. |
| Length with Bucket | 360.0 cm | 142.0 in. |
| Dump Height | 259.3 cm | 102.1 in. |
| Dump Reach | 81.9 cm | 32.2 in. |
| Ground Clearance | 26.5 cm | 10.4 in. |
| Dump Angle | 45 ° | |
| Rollback Angle | 35 ° | |
| Departure Angle | 32 ° | |
| Track Width | 40.1 cm | 15.8 in. |
| Track Length | 299 cm | 117.7 in. |
| Ground Contact Length | 217.1 cm | 85.5 in. |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
