| Manufacturer | Case |
|---|---|
| Type | Compact track loader |
| Model | Tr270 |
| Lift Design | Radial |
| Years Made | 2015-2022 |
| Horsepower | 74.0 HP (55.2 kW) |
| Rating Operating Capacity (35% Tipping) | 1890 lbs (857.3 kg) |
| Rating Operating Capacity (50% Tipping) | 2700 lbs (1224.7 kg) |
| Operating Weight | 8270 lbs (3751.2 kg) |
| Tipping Load | 5400 lbs (2449.4 kg) |
| Lift Breakout Force | 6260 lbs (2839.5 kg) |
| Tilt Breakout Force | 7270 lbs (3297.6 kg) |
| Maximum Travel Speed | 8.0 mph (12.9 km) |
| Pump Capacity | 24.2 GPM (91.5 LPM) |
| Relief Valve Pressure | 3050 psi (210.3 Bar) |
| Optional Pump Capacity | 32.4 GPM (122.6 LPM) |
| Hydraulic Tank Capacity | 8.5 gal (32.2 L) |
| Raise Lift Arms | 3.6 seconds |
| Lower Lift Arms | 1.8 seconds |
| Bucket Rollback | 1.7 seconds |
| Bucket Dump | 2.2 seconds |
| Engine Manufacturer | FPT |
| Engine Model | F5H FL463 A*F001 |
| Engine Type | Diesel |
| No of Cylinders | 4 |
| Rated Speed | 2500 RPM |
| Torque Speed | 1400 RPM |
| Combustion Chamber | Direct injection |
| Emissions | Tier 4F |
| Firing Order | 1-3-4-2 |
| Gross Power | 74.0 HP (55.2 kW) |
| Displacement | 207 cu in. (3392 cc) |
| Bore | 3.9 in. (9.9 cm) |
| Stroke | 4.3 in. (11.0 cm) |
| Peak Torque | 232 ft-lb (314.5 N∙m) |
| Engine Oil Capacity | 2.5 gal (9.4 L) |
| Fuel Tank Capacity | 19.5 gal (73.8 L) |
| Cab Height | 78.7 in. (199.9 cm) |
| Bucket Hinge Pin Height | 123.0 in. (312.4 cm) |
| Width | 65.9 in. (167.4 cm) |
| Length with Bucket | 129.6 in. (329.2 cm) |
| Dump Height | 98.2 in. (249.4 cm) |
| Dump Reach | 25.4 in. (64.5 cm) |
| Ground Clearance | 8.0 in. (20.3 cm) |
| Dump Angle | 40° |
| Rollback Angle | 31° |
| Departure Angle | 32° |
| Track Width | 12.6 in. (32.0 cm) |
| Track Length | 105.1 in. (267.0 cm) |
| Ground Contact Length | 55.9 in. (142.0 cm) |
Case Tr270 Specs (Weight, Lift Capacity, Hp, Dimensions)
