Case 580C vs Ford 555

Specification	Case 580CBackhoe Loaders	Ford 555Backhoe Loaders
Horsepower	42.5 kW (57 HP)	42.5 kW (57.0 HP)
Transmission	Mechanical shuttle	—
Pump Capacity	98.4 LPM (26 GPM)	—
Lift Capacity	2131.9 kg (4700 lbs)	—
Engine Manufacturer	CNH	—
Engine Model	G207D	Ford
Gross Power	42.5 kW (57 HP)	—
Net Power	37.3 kW (50 HP)	—
No Of Cylinders	4	—
Engine Type	Diesel	4-stroke, liquid-cooled, inline
Displacement	3400.3 cc (207.5 cu in)	3294 cc (201.0 cu in.)
Power Measured	2100 RPM	—
Transmission Type	Mechanical shuttle	Torque converter
No Of Forward Gears	8	—
No Of Reverse Gears	8	—
Pump Flow Capacity	98.4 LPM (26 GPM)	—
Dig Depth	426.7 cm (168 in)	—
Dig Depth (Extended)	548.6 cm (216 in)	—
Dump Height	274.3 cm (108 in)	—
Reach From Swivel (Extended)	670.6 cm (264 in)	—
Lift Capacity At Full Height	2131.9 kg (4700 lbs)	—
Bucket Breakout Force	3265.9 kg (7200 lbs)	—
Reach From Swivel	548.6 cm (216 in)	—
Overall Height	335.3 cm (132 in)	—
Wheelbase	213.4 cm (84 in)	203.0 cm (79.9 in.)
Weight	—	6240.0 kg (Loader: 5996.6 lbs (2720.0 kg) Loader and backhoe: 13756.8 lbs)
Length	—	701.0 cm (Loader: 179.9 in. (457.0 cm) Loader and backhoe: 276.0 in.)
Pump Flow	—	102.2 LPM (27.0 GPM)
Years Made	—	1978-1984
Fuel Type	—	Diesel
Cylinders	—	3
Bore	—	11.20 cm (4.41 in.)
Stroke	—	11.20 cm (4.41 in.)
Torque Power	—	1200 RPM
Torque Speed	—	217.0 N·m (160.1 lb-ft)
Rated RPM	—	2200 RPM
Compression Ratio	—	16.3:1
Battery	—	12
Starter	—	Electric
Height	—	276.0 cm (ROPS: 105.9 in. (269.0 cm) Cab: 108.7 in.)
Ground Clearance	—	30.0 cm (11.8 in.)
Fuel Tank Capacity	—	90.8 l (24.0 gal)
Oil Capacity	—	6.6 l (1.7 gal)
Coolant Capacity	—	14.5 l (3.8 gal)
Transmission Oil Capacity	—	18.0 l (4.8 gal)
Hydraulic Capacity	—	79.5 l (Loader: 13.0 gal (49.2 l) Backhoe: 21.0 gal)
Gears	—	4 forward and 4 reverse
Chassis	—	4×2 2WD
Max. Travel Speed	—	32.5 km/h (Forward: 20.2 MPH (32.5 km/h) Reverse: 20.2 MPH)
Brakes	—	Differential mechanical wet disc
Cabin Type	—	Four-post ROPS or Cab
Steering Type	—	Hydrostatic power
Front Tires	—	Ag: 7.50-16
Rear Tires	—	Ag: 16.9-24
Hydraulic Type	—	Open center
Steering Flow	—	22.3 LPM (5.9 GPM)
Working Pressure	—	148.2 bar (2150.0 psi)

Values come from the manufacturer-sourced model files; empty cells mean the property is not published for that model. No performance ranking is applied.
