Bobcat CT120 Specs
Bobcat CT120 compact and multi-purpose tractor specifications: tractor type Compact Utility Tractor, horsepower 15.7 kW, weight 932.0 kg, lift capacity 435.0 kg.
Manufacturer specifications
| Specification | Metric | Imperial |
|---|---|---|
| Tractor Type | Compact Utility Tractor | |
| Horsepower | 15.7 kW | 21.1 HP |
| Weight | 932.0 kg | 2054.7 lbs |
| Lift Capacity | 435.0 kg | 959.0 lbs |
| Transmission Type | Hydrostatic | |
| Length | 268.0 cm | 105.5 in. |
| Years Made | 2008-2010 | |
| Engine Model | Daedong 3C093 | |
| Engine Type | 4-stroke, liquid-cooled, inline | |
| Fuel Type | Diesel | |
| Cylinders | 3 | |
| Displacement | 927 cc | 56.6 cu in. |
| Bore | 7.49 cm | 2.95 in. |
| Stroke | 7.01 cm | 2.76 in. |
| Rear PTO Type | Live | |
| Rear PTO Speed | 540 RPM | |
| Middle PTO Type | Optional | |
| Middle PTO Speed | 2000 RPM | |
| Rated RPM | 2800 RPM | |
| Battery | 12 V | |
| Starter | Electric | |
| Height | 207.0 cm | 81.5 in. |
| Width | 118.0 cm | 46.5 in. |
| Wheelbase | 147.0 cm | 57.9 in. |
| Fuel Tank Capacity | 20.0 l | 5.3 gal |
| Gears | Infinite forward and reverse | |
| Chassis | 4×4 MFWD 4WD | |
| Max. Travel Speed | 9.3 km/h | Forward: 9.3 MPH (15.0 km/h) Reverse: 5.8 MPH |
| Drawbar Category | I | |
| Cabin Type | Open operator station with two-post folding ROPS | |
| Steering Type | Power | |
| Front Tires | Ag: 23×8.5-12, 6×12Lawn/turf: 23×8.5-12 | |
| Rear Tires | Ag: 33×12-16.5, 9.5×16Lawn/turf: 33×12.5-16.5 | |
| Total Flow | 29.1 LPM | 7.7 GPM |
| Valves | 1 |
Source: heavyequipments.net archive (imported 2026-10). Values may vary by variant and production year; seller claims are shown separately on the listing page.
